Input
Phase: Single Phase +N + GND
Voltage Range: 140 Vac ~ 270 Vac (option: 100 ~ 270 V)
Output
Voltage range: 200 ~ 240 V (no load)
Frequency: 50/60 Hz
Overvoltage Protection: 250 V ± 5 V (overvoltage indicator on, output off)
Undervoltage Protection: 180 V ± 5 V (overvoltage indicator on, output off)
Others
Efficiency: ? 95%
Display Mode: LED Indicator Light; Pointer Voltmeter / LCD Display (Selectable)
Input / Output Setting: Plug / Socket
Time-Delay: Short Delay: < 3s; Long Delay: 3 mins
Output Short Circuit Protection: Fuse / Breaker
Waveform Distortion: No Additional Waveform Distortion
Insulation Resistance: > 2MΩ
Dielectric Strenght: Low Frequency Sine Voltage 1500 V for 1 Minute (without phenomena of breakdown and flashover)
Ambient Temperature: -10 degrees C ~ ± 40 degrees C
Relative Humidity: ? 95%
Working: Continuing Working
