Περιγραφή
4G LTE Advanced Cat. 6 up to 300 Mbps DLCalling with VoLTE via 1× RJ11 Port Speedy AC1200 Dual-Band WiFi 4× Gigabit Ports2× Internal 4G Antennas + 2× Internal Wi-Fi Antennas2× SMA Connectors for Extension 4G Antennas (antennas not included)Nano SIM Card SlotVPN Zerotier, Wireguard, OpenVPN, IPSec, L2TP, PPTPCudy Mesh as Main Mesh Node
Model
LT700V
4G
4G UE Category
4G LTE Cat. 6
MIMO, 2-CA
Cellualr Module and Working Bands
EG060W-EA (on EU Model)
LTE-FDD: B1/3/5/7/8/20/28/32;
LTE-TDD: B38/40/41/42 (Optional)/43 (Optional);
Up to 2 × CA: B1+B1/3/5/7/8/20/28; B3+B3/5/7/8/20/28;
B7+B5/7/8/20/28; B20+B32; B38+B38; B40+B40; B41+B41;
B42+B42(Optional); B43+B43(Optional);
WCDMA: B1/5/8
EG060K-NA (on US Model)
LTE-FDD: B2/4/5/7/12/13/14/25/26/29/30/66/71;
LTE-TDD: B41/48
4G Speeds
Up to 300 Mbps Download
Up to 50 Mbps Upload
LTE-FDD: Max 300 Mbps (DL)/Max. 50 Mbps (UL)
LTE-TDD: Max 226 Mbps (DL)/Max. 28 Mbps (UL)
DC-HSDPA: Max 42 Mbps (DL)/HSUPA: Max 5.76 Mbps (UL)
WCDMA: Max 384 Kbps (DL/UL)
Cellular Antennas
2× Internal Antennas
2× External SMA Connectors (Detachble Antennas not Included)
Cellular Features
VoLTE
SMS
Band Lock (Band Select)
TTL Settings
Cellular Data Statistics, Data Limit, SMS Alert for Usage
WAN Failover
Wi-Fi
Wi-Fi Standard
Wi-Fi 5 (802.11ac/n/g/b/a)
Wi-Fi Speeds
AC1200
Up to 867 Mbps on 5 GHz (20/40/80 MHz)
Up to 300 Mbps 2.4 GHz (20/40 MHz)
Wi-Fi Features
MU-MIMO
Beamforming
Transmit Power Adjustment
Wi-Fi Encryption
WPA-PSK
WPA2-PSK
WPA-PSK/WPS2-PSK
Hardware
CPU
880 MHz Dual-Core CPU
ROM
16 MB (128 Mbit) Nor
RAM
128 MB (1 Gbit) DDR3
Ethernet Ports
4× Gigabit Ports
Voice Interfaces
1× RJ11 Port
Buttons
WPS Button, Reset Button, Power On/Off
LED
Power, Network, Wi-Fi, Phone, WAN/LAN, Celluar Signal Strength
Power
DC 12 V ⎓ 1.5 A
Software
VPN
VPN Server and Client
Options: Zerotier, Wireguard, OpenVPN, IPSec, L2TP, PPTP
DNS
Override All Clients DNS, Rebind Protection, DNS Over TLS, Manual DNS
DNS over TLS
Options: Cloudflare, Google, Quad9
Multi-Mode
Router (4G/WAN), WISP (4G as Backup), WISP
Clients Management
Internet Block, Internet/Wi-Fi Schedule, VPN Block, Device Rename
Network Management
QoS, DDNS, WAN/LAN Switch,
Firewall
SPI Firewall, DoS Protection, Block PING
NAT
Port Forwarding, Port Triggering, UPnP, DMZ
TTL
Extend, Spoof, Custom
IPv6
Relay, Dynamic(SLAAC/DHCPv6), Staic (Fixed IP), Passthrough, MAP-E, DS-Lite
DHCP
Server, Client List, Address Reservation
CWMP
TR069, TR098, TR111, TR181, Support STUN
Physical
Dimension (W×D×H)
190×50×148.8 mm
7.48×1.97×5.85 inches
Package Content
4G LTE Router
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
Requirements
Environmental
Operating Temperature: 0 °C – 40 °C (32 °F – 104 °F)
Operating Humidity: 10% – 90 % non-condensing
Storage Temperature: -30 °C – 70 °C (-22 °F – 158 °F)
Storage Humidity: 5% – 95 % non-condensing
System
Windows, MAC OS, NetWare, UNIX, or Linux
Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other Javascript-enabled browser
If you are using 4G as your internet access, you will need a nano SIM card with an active data subscription,
If you are using WAN as your internet access, you will need a fiber/cable/DSL modem or any other wired internet source.
